The need to revise SP 131.13330.2020 “Construction climatology” for the design of urban human habitat

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

The results of the analysis of the provision of the territories of the Russian Federation with weather stations providing climatic information necessary for the design of buildings and development area are presented. The conducted research made it possible to establish that a significant part of the country’s territories are insufficiently provided with climate information, because since the 1990s about 30% of the weather stations presented in SNiP 23-01–99 “Construction Climatology” have been closed. Many stations that stopped providing climate information were removed from the document. And only in 2023, 9 stations were added to the Set of Rules in the newly attached territories of the Donetsk and Lugansk People’s Republics, Zaporizhia and Kherson regions. As a result, the Code of Rules presents specialized climate parameters for 440 localities. However, for the territory of Russia with an area of 17,100 thousand km2, such a network density of weather stations is insufficient and currently it is necessary to expand the list of weather stations in SP 131.13330.2020 “Construction Climatology”. To ensure the process of designing the human habitat and providing the necessary climatic information, during the revision of SP 131.13330.2020 “Construction Climatology”, the provision of all regions of the European and Asian parts of the Russian Federation with weather stations was considered, the location of existing and ceased to provide climatic data of weather stations was analyzed, the sufficiency and insufficiency of providing regions with weather stations receiving climatic data for calculating specialized climatic parameters was assessed, used in the design and construction of buildings and structures, as well as recommended weather stations for inclusion in the Code of Rules of SP 131.13330.2020 “Building climatology”.

Full Text

Restricted Access

About the authors

N. P. Umnyakova

National Research Moscow State University of Civil Engineering; State Geophysical Observatory named after A.I. Voeikov

Author for correspondence.
Email: n.umniakova@mail.ru

Doctor of Sciences (Engineering)

Russian Federation, 26, Yaroslavskoe Highway, Moscow, 129337; 7, Karbysheva Street, St. Petersburg, 194021

M. V. Klueva

Scientific-Research Institute of Building Physics of RAACS

Email: kluevam@yandex.ru

Candidate of Sciences (Geography)

Russian Federation, 21, Lokomotivniy Driveway, Moscow, 127238

V. A. Smirnov

National Research Moscow State University of Civil Engineering; State Geophysical Observatory named after A.I. Voeikov

Email: belohvost@list.ru

Candidate of Sciences (Engineering)

Russian Federation, 26, Yaroslavskoe Highway, Moscow, 129337; 7, Karbysheva Street, St. Petersburg, 194021

References

  1. Lyubomudrov A.A. On the possible cause of global warming on the planet Earth. Innovatsii i investitsii. 2018. No. 10, pp. 201–207. (In Russian).
  2. Biktash L.Z. Influence of the total solar radiation flux to the Earth’s climate. Magnetizm i aeronomiya. 2019. Vol. 59. No. 3, pp. 393–399. (In Russian).
  3. Lyubechansky I.I. Global’noe izmenenie klimata. Kto vinovat? [Global climate change. Who is to blame?]. Novosibirsk: Institute of Systematics and Ecology of Animals SB RAS. 2018. 26 p.
  4. Umnyakova N.P., Shubin I.L. On the problem of revising the Code of Rules SP 131.13330 “Construction Climatology” in a changing climate. Zhilishchnoe Stroitel’stvo [Housing Construction]. 2021. No. 6, pp. 3–10. (In Russian). https://doi.org/10.31659/0044-4472-2021-6-3-10
  5. Umnyakova N.P., Klyueva M.V., Smirnov V.A., Kim D.A. Climatic parameters of new territories of Russia for a set of rules on construction climatology. Promyshlennoe i grazhdanskoe stroitel’stvo. 2023. No. 7, pp. 56–63. (In Russian). https:// doi.org/10.33622/0869-7019.2023.07.56-63
  6. Panchenko T.M., Fedos’ina A.V., Kabanova E.E., Vetrova E.A. Agricultural potential of new regions of Russia. Regional’naya ekonomika. Yug Rossii. 2023. Vol. 11. No. 1, pp. 146–156. (In Russian). https:// doi.org/10.15688/re.volsu.2023.1.14
  7. Chikina Yu.Yu. Features of the formation of a network of meteorological stations on the territory of the Luhansk region. Vestnik Luganskogo natsional’nogo universiteta im. Tarasa Shevchenko. 2018. No. 2 (15), pp. 22–28. (In Russian).
  8. Podlipenskaya L.E., Dolgikh E.D., Gorel’nikov S.A. Investigation of time series of climatic indicators using the method of singular spectral analysis. Ekologicheskiy vestnik Donbassa. 2021. No. 2, pp. 41–49. (In Russian).
  9. Drozd G.Ya., Khvortova M.Yu., Klinchayan A.V. Urban environment of Donbass in the conditions of global warming. Vestnik Luganskogo gosudarstvennogo universiteta im. V. Dalya. 2020. No. 12 (42), pp. 47–56. (In Russian).
  10. Zhizhko N.N. Trends in changes in the main climatic parameters of Donbass (1964–2020). Donetsk Readings 2021: education, science, innovation, culture and modern challenges. Materialy VI Mezhdunarodnoy nauchnoy konferentsii. (Donetsk, October 26–27, 2021). 2021. Vol. 3, pp. 80–83. (In Russian).
  11. Akentieva E.M., Klyueva M.V., Fasolko D.V., Samoilova E.P., Razova E.N. Specialized climate information for the preparation of regional adaptation plans to climate change and variability (on the example of the Leningrad region). Proceedings of the Main Geophysical Observatory named after A.I. Voeikov. 2023. No. 609, pp. 8–29. (In Russian).
  12. Kondratyuk V.I., Svetlova T.P., Ivanova K.M. Ways and problems of climatic zoning of the territory of the Russian Federation. Proceedings of the Main Geophysical Observatory named after A.I. Voeikov. 2015. No. 577, pp. 34–46. (In Russian).
  13. Svetlova T.P. Representativeness of meteorological stations and its influence on the different-scale characteristics of the climatic regime. Proceedings of the Main Geophysical Observatory named after A.I. Voeikov. 2015. No. 579, pp. 115–128. (In Russian).
  14. Pigoltsina G.B. Substantiation of the need and principles of accounting for meso- and microclimate in complex assessments of natural resources taking into account various sectors of the economy. Trudy Glavnoi geofizicheskoi observatorii im. A.I. Voeikova. 2009. No. 560, pp. 89–115. (In Russian).
  15. Lazarev N.I., Kuznetsov N.M. Solar energy for power supply of remote consumers in Murmansk region. Journal of Advanced Research in Technical Science. 2024. № 40. С. 55–58. https://doi.org/10.26160/2474-5901-2024-40-55-58

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. The map of the Murmansk Region

Download (659KB)
Indexing metadata
3. Fig. 2. Layout of meteorological stations in the Murmansk region: red dots – stations included in SP 131.13330.2020; green circles – Roshydromet meteorological stations currently operating in the Murmansk region; red cross – points excluded from SP 131.13330.2020, previously presented by SNIP 23-01-99* ”Building Climatology”, and due to the cessation of their work, closed in the period 2010–2020; in red bold with underlining – stations recommended for adding to SP 131.13330

Download (780KB)
Indexing metadata
4. Fig. 3. Schematic map of the Irkutsk region

Download (956KB)
Indexing metadata
5. Fig. 4. Layout of meteorological stations in the Irkutsk region (for symbols, see Fig. 2)

Download (1MB)
Indexing metadata
